JQX-30F 1Z coil 240VAC Power Relay 8-Pin Plug In Type

Power Source: AC Voltage: 240V
is_customized: Yes Usage: Protective
Model Number: JQX-30F Contact Load: High Power
Protect Feature: Sealed Theory: Electromagnetic Relay
Brand Name: ManHua Certification: CE
Origin: Mainland China Pin number: 8 pins
Contact capacity: 30A 250VAC Coil: AC240V
Terminal Type: Terminal Contact form: 1Z Request quotation

Manhua JQX-30F 1Z coil 240VAC Power Relay 8-Pin Plug In Type

Specification:

Model: JQX-30F

Coil voltage: AC 240V

Contact capacity: 30A 250VAC

Pin Quantities: 8

Appearance: 30A Contact Change-over Capacity With Opening and Dust-Proof Type

Dielectric strength (between coil and contact): 2500VAC

Ambient temperature: -40 ℃ ~ + 70 ℃

Operation / release time: 20ms / 15ms

Mechanical life: 1 * 10 ^ 7

Electrical life: 1* 10 ^ 5


Dimension:


Contact form(wiring drawing):
