EUCR-30N 5-30A electronic underload relay underload phase loss protection relay independently adjustable starting trip delay 5.0 1 Review

Power Source: AC Voltage: 180VAC-480VAC,50/60Hz
is_customized: Yes Usage: Protective
Model Number: EUCR-30N Contact Load: Low Power
Protect Feature: Sealed Theory: Electronic Overload Relay
Brand Name: ManHua Origin: Mainland China
Certification: CE Model: EUCR
Current Range: 5-30A Time Characteristics: Definite Time
Control Voltage: 220) voltage free(90~260)VAC, Rated voltage: 180VAC-480VAC,50/60Hz
Power Consumption: Under 2W Request quotation
Video PDF Download Contact us

EUCR-30N 5-30A electronic underload relay underload phase loss protection relay independently adjustable starting trip delay

Function


1.Underload  and  Phase  Loss Protection


2.Independently adjustable starting  and  Trip  Delay


3.Visual Current Setting Aid and Trip Indication(LED)


4.Flexible Power Supply(90 to 260VAC or 320 to 480VAC)


5.Fail Save Protection(N type)

6.Electronic Sheer-pin function


Technical Data:


Model

EUCR

Current Range

5-30A

Rated Voltage

180-480VAC

Operating Time

 D-TIME  0.2-30sec

O-TIME  0.2-10sec

Time-Current Characteristic

Definite

Operating (Trip) Indication

2-LED

Mount

35mm Din-rail/Panel

Power consumption

Under  2W

Humidity

30-85%RH   Non-condensing
